Synthetic Diamond Micron Powder for Wire Saw Usage

  • Block structure, regular crystal form
  • Uniform particle size distribution
  • Good thermal stability, high wear resistance
  • Used for Used for silicon wafer cutting diamond wire
  • Jewelry diamond wire saw, semiconductor saw etc
DescriptionQualitySizeInquiry

Description

Gradient Diamond metal bond micron diamond is monocrystalline structures with high toughness, regular crystal shape, high particle strength, excellent dispersion. Processed using state-of-the-art grading equipment, our metal bond micron diamond provides well-controlled particle size distribution and surface cleanliness in a wide range of challenging applications.


We provide products customized with particle sizes, shapes, toughness,Magnetism,Surface Cleanliness, Coating, and package methods according to customer requirements.

The uniform blocky crystals are suitable for metal, resin and electroplated bond systems in applications such as grinding ceramics, cemented carbides and glasses. They are also extensively used in polishing and other surface conditioning applications.



Quality

Size

Standard of China Standard of international Mesh Polishing effect Standard of China Standard of international Mesh Polishing effect
W0.1 0-0.1 10000 Super mirror polishing W12 8-12 1600 Normal polishing
W0.25 0-0.25 60000 W14 7-14 1500
W0.5 0-0.5 30000 Mirror polishing W14 8-16 1300
W1 0-1 15000 W20- 10-20 1200
W1.5- 0-2 13000 W20 12-22 1000
W1.5 1-2 12000 Fine polishing W20+ 15-25 800
W2.5 1-3 10000 W28 20-30 700
W3 2-3 7000 W28+ 22-36 600
W3.5 2-4 6500 W40- 20-40 500 Rough grinding
W3.5 2-4 6000 W40 30-40 450
W4 2-5 5000 W40+ 35-45 400
W5 3-6 4000 W50 36-54 350
W6 4-6 3500 325/400 D46 320
W7 4-8 3000 270/325 D54 270
W10 4-9 2500 Normal polishing 230/270 D64 230
W10 5-10 2000 200/230 D76 200
W10 6-12 1800

Inquiry
